Assignment 2 - DVCS

The goal of this assignment is to gain experience working with a Distributed Version Control system. We’ll do this by turning in Assignment 1, and practicing how to check in, update, pull, and merge changes.

This is the most complex assignment in the class because tt is difficult to write a tutorial for it with all the different possibilities of what could go wrong, and even harder to lead 40 people through it at the same time.

However, it is really easy to lead a group through it individually. If you get stuck, make sure to find time to have the instructor lead you through it. Even if it means you have to meet out of class.

One-on-one this is not difficult. Don’t panic if it is confusing, just work on the HTML part of Assignment 1 until you get a chance with the instructor to step through this part.

Turn in Assignment 2

  1. Each person should be checking in at least three .html files. Don’t let your partner check in your files.
  2. You should have a proper directory layout. (See Sample Directory Structure.)
  3. At least one image should be added and used in your project.
  4. One person, and one person only, should Initialize Repository.
  5. That person should Creating Your Project in GitHub.
  6. Then Pushing Code To GitHub For The First Time.
  7. The OTHER people in your project need Cloning Your GitHub Project on Your Computer.
  8. The OTHER people need to add in their files. If your partner goofed checked in all the files, including yours, then go back and delete your three files. Commit the deletion. Then add your three files back in.

How can you make sure you’ve gotten this part done correctly? To grade, I’ll be looking through your check-ins with the Gitk command that you have added three new files. You can type gitk and double-check yourself if you like.

It looks confusing, but I’ve boxed in red the part that says who checked in a file, and that it was a new file:

../../../_images/new_file_check_in.png
  1. Each person should make at least two revisions to his/her own files. Pull, add, commit, and upload the files as shown in Commit and Upload. Here’s an example of a revision. Red text was removed, green text was added.
../../../_images/revision.png
  1. Each commit should have a descriptive comment.
  2. What If You Can’t Push? - You probably need to merge in your with someone else’s changes.
  3. Each person should do a “merge” where files have changed on the server, but in different spots. For example, in the image below both Paul and Daniel made changes based on the copy that was checked in with “Progress with buffered draw commands.” The work was merged by Paul with “Merge branch” check-in. Because Paul did the check-in, he would be the one getting credit. Make sure each team member does a check in with a merge.
../../../_images/merge.png
  1. Each person should do at least one merge where there are file conflicts. Both of you start with the same updated copy. Then both make a different change to the same line. Try to commit, pull, and push. The last one will get an error like:
remote: Counting objects: 3, done.
remote: Compressing objects: 100% (2/2), done.
remote: Total 3 (delta 0), reused 0 (delta 0), pack-reused 0
Unpacking objects: 100% (3/3), done.
From github.com:pvcraven/name_of_my_project
   2390480..834cdc1  master     -> origin/master
Auto-merging index.html
CONFLICT (content): Merge conflict in index.html
Automatic merge failed; fix conflicts and then commit the result.

The file will look something like:

This is a revision of the test file.
Here is a new line. Change by person 1.

You can manually edit and fix the file. Or you can select which of the files to take. Yours, or the other persons. See Step 2A: Merging.

DON’T IGNORE THE CONFLICT! You must fix it before continuing. Otherwise you’ll just leave those weird <<<<< lines in your file.

When you check it in, please label it as a conflicting change so I can find it and easily give you credit.

  1. Paste the GitHub URL for the website and submit Assignment 2 on Scholar.
